The Sun United Kingdom

Media Group: UK National Press (Newspaper)
Media Owner: News UK
Press Centre: News UK
Language: English
URL: www.news.co.uk
Telephone: 020 7782 6000
Email: ci@news.co.uk
Publisher Specs Document:

Address:

1 London Bridge Street
London
SE1 9GF
United Kingdom

logo Logo

Press Specs

  • Section :  Display/ROP
  • Specification: NewspaperAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISOnewspaper26v4.icc
  • Mono ICC Profile: ISOnewspaper26v4_gr.icc
  • Publication Proof Curve: ISOnewspaper26v4.icc
  • Deadline: One working day before insertion.
  • Min Image Res: 150 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 240%
  • Publication Proof Required: No

Additional Section Information:

Columns Display/ROP




Size Type: N/A
Bleed Details: No Bleed
Space Outside Trim: N/A
Indesign Offset: N/A

Click on a column size below then enter height
Columns across a spread sizes in mm.

Columns: 1

Size: mm 34

Enter
Height:
mm

*Max Column Height: 338mm

Full Page Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 264mm x 338mm
  • PDF Size: 264mm x 338mm
Extra Size Information:

Double Page Spread Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 550mm x 338mm
  • PDF Size: 550mm x 338mm
Extra Size Information:

Half Page Horizontal Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 264mm x 170mm
  • PDF Size: 264mm x 170mm
Extra Size Information:

Half Page DPS Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 550mm x 170mm
  • PDF Size: 550mm x 170mm
Extra Size Information:

Barn Door (1/2 horizontal) Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 264mm x 151mm
  • PDF Size: 264mm x 151mm
Extra Size Information:

Earpiece Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 80mm x 8mm
  • PDF Size: 80mm x 8mm
Extra Size Information:

Fire Place Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 320mm x 250mm
  • PDF Size: 320mm x 250mm
Extra Size Information:

TV Box (Large) Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 155mm x 10mm
  • PDF Size: 155mm x 10mm
Extra Size Information:

TV Strip (Special) Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 335mm x 47mm
  • PDF Size: 335mm x 47mm
Extra Size Information:

20x6 Fireplace Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 244mm x 200mm
  • PDF Size: 244mm x 200mm
Extra Size Information:

34x8 Extended Fireplace Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 320mm x 338mm
  • PDF Size: 320mm x 338mm
Extra Size Information:

6 x 6 Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 226mm x 60mm
  • PDF Size: 226mm x 60mm
Extra Size Information:

Chequeboard Box Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 132mm x 168mm
  • PDF Size: 132mm x 168mm
Extra Size Information:

Dear Deidre Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 75mm x 290mm
  • PDF Size: 75mm x 290mm
Extra Size Information:

Innovation Shapes 20x8 Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 320mm x 200mm
  • PDF Size: 320mm x 200mm
Extra Size Information:

Sport 3x10 Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 400mm x 30mm
  • PDF Size: 400mm x 30mm
Extra Size Information:

This is a special size just for Sports section

Sport 3x10 Special Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 396mm x 30mm
  • PDF Size: 396mm x 30mm
Extra Size Information:

Tailed Bokend Strip Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 252mm x 30mm
  • PDF Size: 252mm x 30mm
Extra Size Information:

TV Box Display/ROP

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 34mm x 10mm
  • PDF Size: 34mm x 10mm
Extra Size Information:

  • Section :  Classified
  • Specification: NewspaperAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISOnewspaper26v4.icc
  • Mono ICC Profile: ISOnewspaper26v4_gr.icc
  • Publication Proof Curve: ISOnewspaper26v4.icc
  • Deadline: One working day before insertion.
  • Min Image Res: 150 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 240%
  • Publication Proof Required: No

Additional Section Information:

Columns Classified




Size Type: N/A
Bleed Details: No Bleed
Space Outside Trim: N/A
Indesign Offset: N/A

Click on a column size below then enter height
Columns across a spread sizes in mm.

Columns: 1

Size: mm 30

Enter
Height:
mm

*Max Column Height: 338mm

Double Page Spread Classified

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 550mm x 338mm
  • PDF Size: 550mm x 338mm
Extra Size Information:

Full Page Classified

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 264mm x 338mm
  • PDF Size: 264mm x 338mm
Extra Size Information:

  • Section :  The Sun Magazine Supplement 1
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: MagazineAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: PRI_NP_V2_K1.icc
  • Mono ICC Profile: PRI_NP_Ex88_V2.icc
  • Publication Proof Curve: PRI_NP_Ex88_V2.icc
  • Deadline:
  • Min Image Res: 255 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 360%
  • Publication Proof Required: No

Additional Section Information:

Full Page The Sun Magazine Supplement 1

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 210mm x 275mm
  • Bleed Size: 216mm x 281mm
  • Type Area: 200mm x 265mm
  • PDF Size: 216mm x 281mm
Extra Size Information:

Double Page Spread The Sun Magazine Supplement 1

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 420mm x 275mm
  • Bleed Size: 426mm x 281mm
  • Type Area: 286mm x 200mm
  • PDF Size: 426mm x 281mm
Extra Size Information:

*Please allow 5mm across DPS gutter, 3mm bleed each side on both

Half Page Horizontal The Sun Magazine Supplement 1

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 210mm x 135mm
  • Bleed Size: 216mm x 141mm
  • Type Area: 0mm x 0mm
  • PDF Size: 216mm x 141mm
Extra Size Information:

Half Page Vertical The Sun Magazine Supplement 1

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 105mm x 275mm
  • Bleed Size: 111mm x 281mm
  • Type Area: 0mm x 0mm
  • PDF Size: 111mm x 281mm
Extra Size Information:

Half Page DPS The Sun Magazine Supplement 1

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 420mm x 135mm
  • Bleed Size: 426mm x 141mm
  • Type Area: 0mm x 0mm
  • PDF Size: 426mm x 141mm
Extra Size Information:

  • Section :  The Sun Magazine Supplement 2
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: MagazineAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: SC_paper_eci.icc
  • Mono ICC Profile: Not Applicable
  • Publication Proof Curve: SC_paper_eci.icc
  • Deadline:
  • Min Image Res: 255 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 270%
  • Publication Proof Required: No

Additional Section Information:

Full Page The Sun Magazine Supplement 2

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 210mm x 282mm
  • Bleed Size: 216mm x 288mm
  • Type Area: 200mm x 272mm
  • PDF Size: 216mm x 288mm
Extra Size Information:

Double Page Spread The Sun Magazine Supplement 2

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 420mm x 282mm
  • Bleed Size: 426mm x 288mm
  • Type Area: 410mm x 272mm
  • PDF Size: 426mm x 288mm
Extra Size Information:

*Please allow 5mm across DPS gutter, 3mm bleed each side on both

Half Page Vertical The Sun Magazine Supplement 2

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 98mm x 282mm
  • Bleed Size: 104mm x 288mm
  • Type Area: 93mm x 272mm
  • PDF Size: 104mm x 288mm
Extra Size Information:

Half Page DPS The Sun Magazine Supplement 2

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mmL,R,B-0mmTop
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 420mm x 135mm
  • Bleed Size: 426mm x 138mm
  • Type Area: 410mm x 130mm
  • PDF Size: 426mm x 138mm
Extra Size Information:

1/2 page DPS = 3mm sides and bottom only, bleed should be 426x138

  • Section :  The Sun Magazine Supplement 2 Cover
  • Specification: MagazineAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISO Coated v2 300% (ECI).icc
  • Mono ICC Profile: Not Applicable
  • Publication Proof Curve: ISOcoated_v2_300_eci.icc
  • Deadline:
  • Min Image Res: 255 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 300%
  • Publication Proof Required: No

Additional Section Information:

Full Page The Sun Magazine Supplement 2 Cover

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 210mm x 282mm
  • Bleed Size: 216mm x 288mm
  • Type Area: 200mm x 272mm
  • PDF Size: 216mm x 288mm
Extra Size Information:

Double Page Spread The Sun Magazine Supplement 2 Cover

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 420mm x 282mm
  • Bleed Size: 426mm x 288mm
  • Type Area: 420mm x 230mm
  • PDF Size: 426mm x 288mm
Extra Size Information:

  • Section :  The Sun Magazine Supplement 2 (Gatefold)
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: MagazineAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISO Coated v2 300% (ECI).icc
  • Mono ICC Profile: ISOcoated_v2_300_eci.icc
  • Publication Proof Curve: ISOcoated_v2_eci.icc
  • Deadline:
  • Min Image Res: 255 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info:
  • Gutter Info: Standard
  • TAC (Max Ink): 300%
  • Publication Proof Required: No

Additional Section Information:

Full Page The Sun Magazine Supplement 2 (Gatefold)

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 230mm x 270mm
  • Bleed Size: 236mm x 276mm
  • Type Area: 191mm x 230mm
  • PDF Size: 236mm x 276mm
Extra Size Information:

  • Section :  The Sun Magazine Supplement 3
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: MagazineAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: PRI_NP_V2_K1.icc
  • Mono ICC Profile: Not Applicable
  • Publication Proof Curve: PRI_NP_Ex88_V2.icc
  • Deadline:
  • Min Image Res: 255 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 360%
  • Publication Proof Required: No

Additional Section Information:

Full Page The Sun Magazine Supplement 3

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 233mm x 290mm
  • Bleed Size: 239mm x 296mm
  • Type Area: 216mm x 272mm
  • PDF Size: 239mm x 296mm
Extra Size Information:

Double Page Spread The Sun Magazine Supplement 3

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 466mm x 290mm
  • Bleed Size: 472mm x 296mm
  • Type Area: 448mm x 272mm
  • PDF Size: 472mm x 296mm
Extra Size Information:

*Please allow 5mm across DPS gutter, 3mm bleed each side on both

Half Page Horizontal The Sun Magazine Supplement 3

Logo

Size Type: Type Area Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 216mm x 133mm
  • PDF Size: 216mm x 133mm
Extra Size Information:

Half Page Vertical The Sun Magazine Supplement 3

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 107mm x 272mm
  • PDF Size: 107mm x 272mm
Extra Size Information:

Half Page DPS The Sun Magazine Supplement 3

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 448mm x 133mm
  • PDF Size: 448mm x 133mm
Extra Size Information:

Fabrics The Sun Magazine Supplement 3

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 210mm x 270mm
  • Bleed Size: 216mm x 276mm
  • Type Area: 200mm x 260mm
  • PDF Size: 216mm x 276mm
Extra Size Information:

  • Section :  The Sun Magazine Supplement 4
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: MagazineAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISO Coated v2 300% (ECI).icc
  • Mono ICC Profile:
  • Publication Proof Curve: ISOcoated_v2_eci.icc
  • Deadline:
  • Min Image Res: 255 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 300%
  • Publication Proof Required: No

Additional Section Information:

Full Page The Sun Magazine Supplement 4

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 190mm x 255mm
  • Bleed Size: 196mm x 261mm
  • Type Area: 0mm x 0mm
  • PDF Size: 196mm x 261mm
Extra Size Information:

Columns The Sun Magazine Supplement 4



Size Type: N/A
Bleed Details:
Space Outside Trim: N/A
Indesign Offset: N/A

Click on a column size below then enter height

Columns: 1

Size: mm 0

Enter
Height:
mm

*Max Column Height: 255mm

  • Section :  The Sun Magazine Supplement A5
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: MagazineAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: PRI_NP_V2_K1.icc
  • Mono ICC Profile: PRI_NP_Ex88_V2.icc
  • Publication Proof Curve: PRI_NP_Ex88_V2.icc
  • Deadline:
  • Min Image Res: 255 ppi
  • Min Bitmap Res: 300 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 360%
  • Publication Proof Required: No

Additional Section Information:

Full Page The Sun Magazine Supplement A5

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 148mm x 210mm
  • Bleed Size: 154mm x 216mm
  • Type Area: 138mm x 200mm
  • PDF Size: 154mm x 216mm
Extra Size Information:

Double Page Spread The Sun Magazine Supplement A5

Logo

Size Type: Trim & Bleed Only
Bleed Details: 3mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 296mm x 210mm
  • Bleed Size: 302mm x 216mm
  • Type Area: 286mm x 200mm
  • PDF Size: 302mm x 216mm
Extra Size Information:

*Please allow 5mm across DPS gutter, 3mm bleed each side on both

  • Section :  Sun TV Supplement National
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: NewspaperAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISOnewspaper26v4.icc
  • Mono ICC Profile: ISOnewspaper26v4_gr.icc
  • Publication Proof Curve: ISOnewspaper26v4.icc
  • Deadline:
  • Min Image Res: 150 ppi
  • Min Bitmap Res: 1200 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 240%
  • Publication Proof Required: No

Additional Section Information:

Full Page Sun TV Supplement National

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm top and bottom, 10mm left and right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 265mm x 333mm
  • Bleed Size: 285mm x 343mm
  • Type Area: 245mm x 313mm
  • PDF Size: 285mm x 343mm
Extra Size Information:

Double Page Spread Sun TV Supplement National

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm top and bottom, 10mm left and right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 530mm x 333mm
  • Bleed Size: 550mm x 343mm
  • Type Area: 510mm x 313mm
  • PDF Size: 550mm x 343mm
Extra Size Information:

Supply As single file

Half Page Horizontal Sun TV Supplement National

Logo

Size Type: Trim & Bleed Only
Bleed Details: 0mm top, 5mm bottom, 10mm left, 10mm right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 265mm x 166.5mm
  • Bleed Size: 285mm x 171.5mm
  • Type Area: 245mm x 157mm
  • PDF Size: 285mm x 171.5mm
Extra Size Information:

adverts need bleed to the left, right and bottom only.

Half Page Vertical Sun TV Supplement National

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm top and bottom, 10mm left and right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 134mm x 333mm
  • Bleed Size: 154mm x 343mm
  • Type Area: 124mm x 313mm
  • PDF Size: 154mm x 343mm
Extra Size Information:

Bookend Sun TV Supplement National

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 130mm x 333mm
  • Bleed Size: 140mm x 343mm
  • Type Area: 110mm x 313mm
  • PDF Size: 140mm x 343mm
Extra Size Information:

Columns Sun TV Supplement National



Size Type: N/A
Bleed Details:
Space Outside Trim: N/A
Indesign Offset: N/A

Click on a column size below then enter height

Columns: 1

Size: mm 0

Enter
Height:
mm

*Max Column Height: 313mm

  • Section :  Broadsheet_Sup
  • Contact:
  • Phone:
  • Email:
  • Repeat Email:
  • Specification: NewspaperAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISOnewspaper26v4.icc
  • Mono ICC Profile: ISOnewspaper26v4_gr.icc
  • Publication Proof Curve: ISOnewspaper26v4.icc
  • Deadline:
  • Min Image Res: 150 ppi
  • Min Bitmap Res: 1200 ppi
  • Double Page Info:
  • Gutter Info: Standard
  • TAC (Max Ink): 240%
  • Publication Proof Required: No

Additional Section Information:

Columns Broadsheet_Sup




Size Type: N/A
Bleed Details:
Space Outside Trim: N/A
Indesign Offset: N/A

Click on a column size below then enter height
Columns across a spread sizes in mm.

Columns: 1

Size: mm 39

Enter
Height:
mm

*Max Column Height: 540mm

Full Page Broadsheet_Sup

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 343mm x 540mm
  • PDF Size: 343mm x 540mm
Extra Size Information:

Double Page Spread Broadsheet_Sup

Logo

Size Type: Type Area Only
Bleed Details: No Bleed
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Type Area: 711mm x 540mm
  • PDF Size: 711mm x 540mm
Extra Size Information:

Please supply as a single file

  • Section :  Sun TV Supplement Ireland
  • Specification: NewspaperAds_1v4
  • PDF Standard: PDF/X-1a:2001
  • Colour ICC Profile: ISOnewspaper26v4.icc
  • Mono ICC Profile: ISOnewspaper26v4_gr.icc
  • Publication Proof Curve: ISOnewspaper26v4.icc
  • Deadline:
  • Min Image Res: 150 ppi
  • Min Bitmap Res: 1200 ppi
  • Double Page Info: Supply as a Single File
  • Gutter Info: Standard
  • TAC (Max Ink): 240%
  • Publication Proof Required: No

Additional Section Information:

Full Page Sun TV Supplement Ireland

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm top and bottom, 10mm left and right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 265mm x 333mm
  • Bleed Size: 285mm x 343mm
  • Type Area: 245mm x 313mm
  • PDF Size: 285mm x 343mm
Extra Size Information:

Double Page Spread Sun TV Supplement Ireland

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm top and bottom, 10mm left and right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 530mm x 333mm
  • Bleed Size: 550mm x 343mm
  • Type Area: 510mm x 313mm
  • PDF Size: 550mm x 343mm
Extra Size Information:

Half Page Horizontal Sun TV Supplement Ireland

Logo

Size Type: Trim & Bleed Only
Bleed Details: 0mm top, 5mm bottom, 10mm left, 10mm right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 265mm x 166.5mm
  • Bleed Size: 285mm x 171.5mm
  • Type Area: 245mm x 157mm
  • PDF Size: 285mm x 171.5mm
Extra Size Information:

Half Page Vertical Sun TV Supplement Ireland

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm top and bottom, 10mm left and right
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 134mm x 333mm
  • Bleed Size: 154mm x 343mm
  • Type Area: 124mm x 313mm
  • PDF Size: 154mm x 343mm
Extra Size Information:

Bookend Sun TV Supplement Ireland

Logo

Size Type: Trim & Bleed Only
Bleed Details: 5mm on all sides
Space Outside Trim: N/A
InDesign Offset: N/A

WidthHeight

  • Trim Size: 130mm x 333mm
  • Bleed Size: 140mm x 343mm
  • Type Area: 110mm x 313mm
  • PDF Size: 140mm x 343mm
Extra Size Information:

Columns Sun TV Supplement Ireland



Size Type: N/A
Bleed Details:
Space Outside Trim: N/A
Indesign Offset: N/A

Click on a column size below then enter height

Columns: 1

Size: mm 0

Enter
Height:
mm

*Max Column Height: 313mm

Digital Specs

  • Section:  Mobile-IOS
  • Contact: Digital Production
  • Phone: 020 7782 7777
  • Email: digitaladoperations@news.co.uk
  • Copy Deadline: Copy must be supplied correctly 3 working days before publication.
More ...

300x100 Mobile-IOS

Format: JPG, GIF, PNG
Resolution:
Max Weight:
Hot Spots: No
Flash Supported: No

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 300px x 100px
Extra Size Information:

iOS - iPhone/iPod Touch – 300x100

  • Section:  Web Formats
More ...

BillBoard (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 970px x 250px
Extra Size Information:

Expanded by default, Clear close button collapsing ad (When a user clicks ‘Close Ad X’ the ad will collapse, 100% leaving a ‘Show Ad’ button)

Carousel (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 138px x 150px
  • Expanded Size: 600px x 336px
Extra Size Information:

Splash – 600x336, Thumbnail – 138x150

Double MPU (Static-Animated) Web Formats

Format: JPG, JPEG, PNG, MP4
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 300px x 600px
Extra Size Information:

Expanding Leaderboard (Rich-Interactive) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: Yes
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 728px x 90px
  • Expanded Size: 728px x 350px
Extra Size Information:

Downward expansion only on User Click to open. Immediate auto-contraction on roll-off. No Push-Down creative. No auto expansion permitted. 3rd Party Ad Served only. Lead time 5 working days for testing – Editorial Approval Required. Applies to Expanding Creative : Expansion panel must appear over page content on user click ONLY Clear ‘Click to expand’ text must be included on the ad Clear ‘Close X’ button included top right hand corner Roll off to close. No Expanding ads on Classified pages.

Expanding Leaderboard (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 728px x 90px
  • Expanded Size: 728px x 350px
Extra Size Information:

728x90, 3rd party served

Expanding MPU Above The Fold (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 300px x 250px
  • Expanded Size: 600px x 250px
Extra Size Information:

Leaderboard (Rich-Interactive) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: Yes
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 728px x 90px
Extra Size Information:

Downward expansion only on User Click to open. Immediate auto-contraction on roll-off. No Push-Down creative. No auto expansion permitted. 3rd Party Ad Served only. Lead time 5 working days for testing – Editorial Approval Required. Applies to Expanding Creative : Expansion panel must appear over page content on user click ONLY Clear ‘Click to expand’ text must be included on the ad Clear ‘Close X’ button included top right hand corner Roll off to close. No Expanding ads on Classified pages.

Leaderboard (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 728px x 90px
Extra Size Information:

MPU Above The Fold (Rich-Interactive) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: Yes
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 300px x 250px
Extra Size Information:

Downward expansion only on User Click to open. Immediate auto-contraction on roll-off. No Push-Down creative. No auto expansion permitted. 3rd Party Ad Served only. Lead time 5 working days for testing – Editorial Approval Required. Applies to Expanding Creative : Expansion panel must appear over page content on user click ONLY Clear ‘Click to expand’ text must be included on the ad Clear ‘Close X’ button included top right hand corner Roll off to close. No Expanding ads on Classified pages.

MPU Above The Fold (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 300px x 250px
Extra Size Information:

Audio off by default, 1 pixel black border, Maximum 3 Loops

Overlay (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 970px x 90px
  • Expanded Size: 970px x 418px
Extra Size Information:

On-click ONLY, Index Pages ONLY (970 x 418) Roll off to close

Pushdown Through The SIite (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 970px x 90px
  • Expanded Size: 970px x 418px
Extra Size Information:

On-click ONLY, Index Pages ONLY (970 x 418) Roll off to close

Skins (Static-Animated) Web Formats

Format: Jpeg
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size:

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 1920px x 1320px
Extra Size Information:

CONTENT EXCLUSION AREA: 980 pixel central exclusion area TEXT SAFE AREA: Make sure that important information and messaging confined to the text safe area highlighted in green on the template here. This measures 140 x 830 px (width x height) on both sides. This is the only part outside of the site content area that is viewable on monitor resolutions of 1280 x1024 (our most popular screen size by far (over 50%) The area outside of this indicated in red on the template must be filled with a solid colour.

Super Expanding MPU Above The Fold (Static-Animated) Web Formats

Format:
Type:Banners
Flash Supported: Yes
Video Supported: No
Max file size: 40KB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 300px x 250px
  • Expanded Size: 980px x 650px
Extra Size Information:

On-click ONLY, Contract on mouse-exit Expand to: 980 x 650

Roadblock 300x250 Web Formats

Format: JPEG, BMP, GIF
Type:Banners
Flash Supported: No
Video Supported: No
Max file size: 10MB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 300px x 250px
Extra Size Information:

Roadblock 320x50 Web Formats

Format: JPEG, BMP, GIF
Type:Banners
Flash Supported: No
Video Supported: No
Max file size: 10MB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 320px x 50px
Extra Size Information:

Roadblock 728x60 Web Formats

Format: GIF, animated GIF, JPEG
Type:Banners
Flash Supported: No
Video Supported: No
Max file size: 10MB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 728px x 60px
Extra Size Information:

Roadblock 970x250 Web Formats

Format: JPG, GIF, PNG
Type:Banners
Flash Supported: No
Video Supported: No
Max file size: 10MB

View Detailed Ad Spec

WidthHeight

  • Fixed Size: 970px x 250px
Extra Size Information:

© 2024 Qmuli Ltd User Licence Agreement4/4A Bloomsbury Square, London, WC1A 2RP, 020 7278 4009 support@qmuli.com

All files sent via ad.fast are accepted subject to the ad.fast User Licence Agreement
